規格		Gap	Straight	Gap	Straight	Gap	Straight	Gap	Straight
Specifications		C6232D	C6132D	C6236D	C6136D	C6240D	C6140D	C6250D	C6150D
中心高Center height		160mm		180mm		200mm		250mm
床身上更大工件直徑Max. Swing over bed		320mm		360mm		400mm		500mm
刀架上更大工件直徑Max. Swing over carriage		190mm		190mm		210mm		210mm
馬鞍槽更大工件直徑Max. Swing in gap		520mm	-	540mm	-	560mm	-	590mm	-
馬鞍槽有效長度Effective gap length		200mm	-	200mm	-	200mm	-	200mm	-
更大工件長度Max. Length of work piece		500mm or 750mm or 1000mm or 1500mm
主軸孔錐度Spindle taper		MT 6
主軸通孔直徑Thru-hole of spindle		52mm/80
轉速范圍Spindle speeds		30—1600 r/min (12 steps)
橫刀架行程Cross travel		240mm
小刀架行程Compound travel		140mm
尾座行程Tail stock center sleeve travel		90mm
尾座套筒錐度Tail stock center sleeve taper		MT 4
電機功率Motor		3/4KW
公制螺紋Range of metric threads (kinds)		0.45-20mm(30)
英制螺紋Range of inch threads(kinds)		80-1.75 n/ I”
縱向進給量Long. Feed per spindle rev.		0.04-2.16mm
橫向進給量Cross feed per spindle rev.		0.02-1.08 mm
外形尺寸	Overall dimensions for 500mm	170011301200 mm
	Overall dimensions for 750mm	200011301540 mm
	Overall dimensions for 1000mm	225011301540 mm
	Overall dimensions for 1500mm	280011301540 mm
凈重	Net weight of 500mm	1200kg				1300kg		1500 kg
	Net weight of 750mm	1400kg				1500kg		1700kg
	Net weight of 1000mm	1500kg				1600kg		1700kg
	Net weight of 1500mm	1700kg				1800kg		2000kg
